CHA7115-99F - X Band HPA
Gain (dB)
27.5
Sat. Output Power (dBm)
39
Bias (mA)
2200
Bias (V)
8
IP3 (dBm)
-
P-1dB OUT (dBm)
-
PAE (%)
37 @ 4dB comp
RF Bandwidth (GHz) Max
11.5
RF Bandwidth (GHz) Min
8.5
The CHA7115-99F is a monolithic three-stage GaAs high power amplifier designed for X band applications.
This HPA provides typically 8W output power associated to 36% power added efficiency at 4dBcomp and a high robustness on mismatch load.
This device is manufactured using 0.25µm Power pHEMT process, including, via holes through the substrate and air bridges.
It is available in chip form.
