CHV2411aQDG - Fully integrated HBT K band VCO
Output Power (dBm)
16
Bias (mA)
220
Bias (V)
5
Central Output Freq
24,125
Noise @100KHz (dBc/Hz)
-90
Tuning Bandwidth (GHz)
2
Market
Automotive
The CHV2411aQDG is a monolithic multifunction for frequency generation. It integrates an X-band “push-push” oscillator with frequency control (VCO) thanks to base collector diodes, used as varactors, a K-band buffer amplifiers and a divider by 8. The VCO is fully integrated on HBT process. All the active devices are internally self biased.
The circuit is fully integrated on InGaP HBT process: 2µm emitter length, via holes through the substrate and high Q passive elements.
The chip is delivered in a 24 Leads RoHS compliant QFN4x4 package.
