CHS7012-99F - DC-12GHz reflective SPDT
Isolation (dB)
30
Loss (dB)
1.4
P-1dB IN (dBm)
40.5
RF Bandwidth (GHz) Max
12
RF Bandwidth (GHz) Min
DC
Type
reflective
Market
Aerospace, Defense and Instrumentation
The CHS7012-99F is a monolithic FET based reflective switch in the DC-12GHz frequency band.
It is designed for a wide range of applications, from military to commercial communication systems.
It is developed on a robust 0.25µm gate length GaN/SiC pHEMT process and is available as bare die.
