CHS5105-QAG - DC-4GHz reflective SPDT
Isolation (dB)
35
Loss (dB)
0.5
P-1dB IN (dBm)
30
RF Bandwidth (GHz) Max
4
RF Bandwidth (GHz) Min
DC
Type
reflective
Market
Aerospace, Defense and Instrumentation
The CHS5105-QAG is a monolithic FET based reflective switch.
It is designed for a wide range of applications, from military to commercial systems.
The circuit is manufactured with a pHEMT process, 0.25µm gate length, via holes through the substrate, air bridges and electron beam gate lithography.
It is supplied in RoHS compliant SMD package.
