CHR3861-QEG - 6-9GHz Integrated Down Converter
Conv. Gain (dB)
12
Bias (mA)
380
Bias (V)
4
IF Bandwidth (GHz)
DC-3.5
LO Bandwidth (GHz)
3-12.5
Noise Figure (dB)
2.5
P-1dB IN (dBm)
-7
RF Bandwidth (GHz) Max
9
RF Bandwidth (GHz) Min
5.5
Market
6-8.5GHz Chipset
The CHR3861-QEG is a multifunction part, which integrates a balanced cold FET mixer, a LO bufffer, and a RF LNA including gain control. It is designed for a wide range of applications, typically ISM and commercial communication systems.
The circuit is manufactured on a pHEMT process, 0.25µm gate length.
It is supplied in lead-free SMD package.
