CHR2421-QEG - 23.75-24.5GHz Dual Rx Channel
Conv. Gain (dB)
22
LO Input Power (dBm)
2
Bias (mA)
165
Bias (V)
5
IF Bandwidth (GHz)
DC-0.001
LO Bandwidth (GHz)
23.75-24.5
Noise Figure (dB)
7
P-1dB IN (dBm)
-20
RF Bandwidth (GHz) Max
24.5
RF Bandwidth (GHz) Min
23.75
Market
Automotive
The CHR2421-QEG is a monolithic multifunction dual channel receiver in K-Band which integrates low noise amplifiers and mixers providing an IF signal from DC to 1 MHz. All the active devices are self biased on chip.
The circuit is dedicated to sensors and also well suited for a wide range of microwave and millimetre wave applications and systems.
The circuit is manufactured with a pHEMT process, 0.25µm gate length.
It is supplied in a 24 leads RoHS compliant QFN4x5 package.
