CHA6653-QXG - 27-33.5GHz Power Amplifier
Gain (dB)
20
Sat. Output Power (dBm)
33
Bias (mA)
700
Bias (V)
6
IP3 (dBm)
38
P-1dB OUT (dBm)
32
PAE (%)
23 @ Psat
RF Bandwidth (GHz) Max
33.5
RF Bandwidth (GHz) Min
27
Market
28-32GHz & VSAT Ka Chipset
The CHA6653-QXG is a four stage monolithic GaAs high power circuit producing 1.8 Watt output power. It is highly linear, with possible gain control and integrates a power detector. ESD protections are included.
It is designed for Point To Point Radio.
The circuit is manufactured with a pHEMT process, 0.15µm gate length.
It is supplied in RoHS compliant SMD package.
