CHA6652-QXG - 21-27.5GHz Power Amplifier
Gain (dB)
20
Sat. Output Power (dBm)
33
Bias (mA)
1300
Bias (V)
6
IP3 (dBm)
41
P-1dB OUT (dBm)
32.5
PAE (%)
25 @ Psat
RF Bandwidth (GHz) Max
27.5
RF Bandwidth (GHz) Min
21
Market
23-26GHz Chipset
The CHA6652-QXG is a three stage monolithic GaAs high power circuit producing 2 Watt output power. It is highly linear, with possible gain control and integrates a power detector. ESD protections are included.
It is designed for Point To Point Radio.
The circuit is manufactured with a pHEMT process, 0.15µm gate length.
It is supplied in RoHS compliant SMD package.
