CHA4253a98F - 17-24GHz Medium Power Amplifier
Gain (dB)
26
Sat. Output Power (dBm)
25
Bias (mA)
230
Bias (V)
4
IP3 (dBm)
32
P-1dB OUT (dBm)
24.5
RF Bandwidth (GHz) Max
24
RF Bandwidth (GHz) Min
17
Market
13-18GHz & VSAT Ku Chipset
The CHA4253a98F is a four stage monolithic Medium Power Amplifier.
It is designed for a wide range of applications, from Point To Point Radio and K band to other commercial communication systems.
The circuit is manufactured with a pHEMT process, 0.15µm gate length.
It is available in chip form.
