CHA3664-QAG - 5-21GHz Driver Amplifier
Gain (dB)
15
Sat. Output Power (dBm)
20.5
Bias (mA)
120
Bias (V)
5
IP3 (dBm)
25
P-1dB OUT (dBm)
19.5
RF Bandwidth (GHz) Max
21
RF Bandwidth (GHz) Min
5
Market
13-18GHz & VSAT Ku Chipset
The CHA3664-QAG is a two-stage general purpose monolithic Medium Power Amplifier.
It is designed for a wide range of applications, from military to commercial communication systems.
The circuit is manufactured with a power pHEMT process, 0.25µm gate length, via holes through the substrate, air bridges and electron beam gate lithography.
It is supplied in RoHS compliant SMD package.
