CHA3063-99F - 5.5-23GHz Driver Amplifier
Gain (dB)
19
Sat. Output Power (dBm)
21
Bias (mA)
160
Bias (V)
4
IP3 (dBm)
28
P-1dB OUT (dBm)
18
RF Bandwidth (GHz) Max
23
RF Bandwidth (GHz) Min
5.5
Market
6-18GHz Chipset
The CHA3063-99F is a two-stage general purpose monolithic Medium Power Amplifier.The backside of the chip is both RF and DC grounded.This helps to simplify the assembly process.
The circuit is manufactured with a pHemt process: 0.25µm gate length, via holes through the substrate, air bridges and electron beam gate lithography.
It is supplied in chip form.
