CHA2190-99F - 20-30GHz LNA
Gain (dB)
15
Gain Flatness (+/-dB)
0.5
Bias (mA)
50
Bias (V)
4
Noise Figure (dB)
2.2
P-1dB OUT (dBm)
11
RF Bandwidth (GHz) Min
20
RF Bandwidth (GHz) Max
30
Market
28-32GHz & VSAT Ka Chipset
The CHA2190-99F is a two-stage self biased wide band monolithic Low Noise Amplifier.
The circuit is manufactured with a standard pHEMT process: 0.25µm gate length, via holes through the substrate, air bridges and electron beam gate lithography.
It is supplied in chip form.
